ArrowJet Hybrid Pro M
  • ArrowJet Hybrid Pro M Logo

Product ID: 18829

New Listing

Year: New
Make: ArrowJet
Model: Hybrid Pro M

Click here to contact us about this product »

Welcome to the Future of Label and Flexible Packaging Printing with ArrowJet Hybrid M Series!

Elevate your label and flexible packaging printing to new heights with the cutting-edge ArrowJet Hybrid M Series. Engineered specifically for the demands of this dynamic industry, our advanced features redefine the standards:

  • Inline Rotary Slitter or Lamination
  • High-Speed Gap and BM Sensor
  • RIP Software
  • Inline NIR Dryer Module

Precision Tailored for Labels:

Experience unparalleled precision with CMYK Single Printhead Memjet Duraflex technology. The ArrowJet Hybrid M Series boasts a remarkable resolution of 1600x1600dpi or 1600x954dpi, ensuring that every label and flexible packaging detail is captured with utmost clarity.

Speed Meets Quality:

Boost your production with exceptional speeds of up to 90 ft/min (27.4m/min) or 190 ft/min (45.7 m/min). The ArrowJet Hybrid M Series combines speed and quality, ensuring your labels and flexible packaging are printed efficiently without compromising on excellence.

Versatility for Flexible Creativity:

Unleash your creativity with a maximum media width of 15.75″ (400mm) and a maximum printing width of 12.75″ (324mm). The ArrowJet Hybrid M Series supports a variety of materials, including coated paper, PP, PET, PVC, BOPP, Mylar, Tyvek, and more.

Ink Excellence:

Choose from 2L or 10L CMYK tank options to meet your specific ink requirements. Our high durability pigmented aqueous inkjet guarantees vibrant and long-lasting prints that stand out on your labels and flexible packaging.

Intelligent Design for Labels:

Experience seamless label and flexible packaging printing with our modular design featuring digital tension control. The ArrowJet Hybrid M Series includes inline primer & varnish stations with an inline IR dryer, optimizing the printing process for labels and flexible packaging.

Precision Web Handling for Packaging:

Achieve accurate and smooth printing with a web speed of up to 50m/min. The ArrowJet Hybrid M Series ensures precise handling, making it the perfect choice for intricate label and flexible packaging designs.

Tailored Configuration:

Customize your printing experience with optional features like an inline rotary slitter or lamination, high-speed gap and BM sensor, and RIP software. The ArrowJet Hybrid M Series adapts to the unique requirements of label and flexible packaging printing.

Environmentally Friendly Printing:

Operating at a temperature range of 68-86°F (20-30°C) and a storage temperature of 50-104°F (10-40°C), the ArrowJet Hybrid M Series promotes sustainability in label and flexible packaging printing operations.

Compact Powerhouse for Packaging:

Measuring at 71.8’×56.1’×57.9″ (5398mm x 1455mm x 1750mm), the ArrowJet Hybrid M Series is a compact powerhouse specifically designed to excel in label and flexible packaging printing.

Reliable Power Source for Packaging:

Powered by a three-phase 400v AC + N+E, the ArrowJet Hybrid M Series ensures a stable and reliable power supply for uninterrupted label and flexible packaging printing.
Step into the future of label and flexible packaging printing with the ArrowJet Hybrid M Series – where innovation meets the unique demands of your industry, and your printing capabilities soar to new heights. Explore the possibilities today!

Features

  • Printing Color CMYK Single Printhead Memjet Duraflex technology
  • Printing Resolution 1600x1600dpi, 1600x954dpi or 1600×640
  • Printing Speed 90 ft/min, 150 ft/min or 195 ft/min*
  • Max Media Width 15.75″ (400mm)
  • Max Printing Width 12.75″ (324mm)
  • Max Roll Unwind Diameter 23.6″ (600mm)
  • Max Roll Rewind Diameter 23.6″ (600mm) (300 mm in case slitting)
  • Core Size 3″ (76.3mm)
  • Min. Substrate Thickness 2 mil (0.05mm)
  • Max. Substrate Thickness 13.75 mil (0.35mm)
  • Material Supported Coated Paper, PP, PET, PVC, BOPP, Mylar, Tyvek and More
  • Ink Capacity 2L or 10L CMYK Tank options available
  • Web Handling System Modular Design with Digital Tension Control
  • Web Speed up to 50m/min
  • Features Inline Primer & Varnish Stations w/ inline IR Dryer
  • Printing Platform High Durability Pigmented Aqueous Inkjet
  • Operating Temperature 68-86° F (20-30°C), Relative humidity 30-50% Non Condensing
  • Storage Temperature 50-104° F (10-40°C), Relative humidity 65% Non Condensing
  • Equipment Dimension (Lx W x H) 212.5″‘x 57.2″ x 57.1″ (5398mm x 1455mm x 1704mm)
  • Power Requirements Three phase 400V AC + N+E
  • Air source Requirements 6 Bar
  • Optional In-line Rotary Slitter or Lamination High Speed Gap and BM Sensor RIP Software Inline NIR Dryer Module Additional Flexo Stations Web Handling Speed Increase (150mpm)
